Edelbrock Crate Engine Eforce Supercharged LS 416 CI w/ Complete - 46760

Edelbrock Supercharged LS 416 crate engine part 46760 produces 720 horsepower and 695 ft-lbs. of torque, on 91 octane pump gas. The foundation is a brand new, aluminum LS3 block with a forged and balanced Manley crankshaft, forged Manley H-Beam connecting rods and Manley forged aluminum pistons. Sitting on top is an Edelbrock E-Force supercharger system with Eaton TVS 2300cc/rev rotors. Also included are supercharger kit components, such as the electric intercooler water pump, intercooler plumbing and intercooler recovery tank, as well as fuel rails, 60 lb./hr. fuel injectors, mass air flow sensor (MAFS) housing and re-usable air filter. The supercharger on this engine has a driver's side throttle body orientation for ease of intake routing and a Corvette belt offset. Pair with universal heat exchangers for a complete installation.

Engine Specifications:

• Displacement: 416 c.i.d.
• Bore: 4.065"
• Stroke: 4.000"
• Horsepower: 720 hp
• Torque: 695 ft-lbs.
• Compression: 9.5:1
• Block: LS3 Aluminum
• Crankshaft: Forged 4340
• Pistons: Forged Aluminum - 18cc
• Rods: Forged H-Beam
• Camshafts: 215 Deg /247 Deg , .629/.656, 121 LSA
• Rocker Arms: LS3, 1.7 ratio
• Induction: E-Force Supercharger System #1540
• Cylinder Heads: GM with Edelbrock Valve Springs #5768
• Finish: Black powder coated
• Warranty: 2-year / Unlimited mileage

Whether its for a full rebuild or some standard maintenance, the proper engine components are needed to make sure your vehicle is running smooth.

Founded in 1938, Torrance-based Edelbrock, LLC is recognized as one of the nation's premier designers, manufacturers and distributor of performance replacement parts for the automotive aftermarket. Edelbrock produces their core products in the United States of America using state-of-the-art equipment in their world class manufacturing facilities. Edelbrock, LLC encompasses five locations in Southern California and one location in North Carolina totaling more than 500,000 square feet.
